DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

Parameter Description

one of the authentication keys.

Click the Apply button to accept the changes made.

The fields that can be configured in NTP Update Calendar are described below:

Parameter Description

NTP Update Calendar

Select to enable or disable the NTP update calendar feature here. This is used to

periodically update the hardware clock from an NTP source.

Click the Apply button to accept the changes made.

The fields that can be configured in NTP Settings are described below:

Parameter Description

NTP Master Stratum

Enter the NTP master stratum value here. This is used to configure the Real-Time

Clock (RTC) as an NTP master clock when an external NTP is not available. The

range is from 1 to 15.

Select the Default option to use the default value.

NTP Max Associations

Enter the NTP maximum association value here. This is used to configure the

maximum number of NTP peers and clients on the Switch. The range is from 1 to

64.

Click the Apply button to accept the changes made.

NTP Server Settings

This window is used to display and configure the NTP server settings. This is used to enable the Switch to

synchronize time with an NTP server.

To view the following window, click Management > NTP > NTP Server Settings, as shown below:

Figure 4-72 NTP Server Settings Window

The fields that can be configured are described below:

Parameter Description

IP Address

Select and enter the IPv4 address of the NTP server here.

IPv6 Address

Select and enter the IPv6 address of the NTP server here.

Version

Enter the NTP version number here. The range is from 1 to 4.

Key ID

Enter the authentication key ID here. The range is from 1 to 255.
