DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

136

To view the following window, click L2 Features > FDB > MAC Address Table, as shown below:

Figure 5-6 MAC Address Table Window

The fields that can be configured are described below:

Parameter Description

Port

Select the stacking unit ID and the port number of the Switch that will be

configured here.

VID

Enter the VLAN ID that will be used for this configuration here.

MAC Address

Enter the MAC address that will be used for this configuration here.

Click the Clear Dynamic by Port button to clear the dynamic MAC address listed on the corresponding port.

Click the Clear Dynamic by VLAN button to clear the dynamic MAC address listed on the corresponding VLAN.

Click the Clear Dynamic by MAC button to clear the dynamic MAC address entered.

Click the Find button to locate a specific entry based on the information entered.

Click the Clear All button to clear all dynamic MAC addresses.

Click the Show All button to display all the MAC addresses recorded in the MAC address table.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

MAC Notification

This window is used to display and configure MAC notification.
