DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

Click the Back button to return to the previous window.

Telnet/Web

This window is used to display and configure Telnet and Web settings on the Switch.

To view the following window, click Management > Telnet/Web, as shown below:

Figure 4-26 Telnet/Web Window

The fields that can be configured in Telnet Settings are described below:

Parameter Description

Telnet State

Select to enable or disable the Telnet server feature here.

Port

Enter the TCP port number used for Telnet management of the Switch. The well-

known TCP port for the Telnet protocol is 23.

Click the Apply button to accept the changes made.

The fields that can be configured in Source Interface are described below:

Parameter Description

Source Interface State

Select to enable or disable the source interface’s state here.

Type

Select the type of source interface that will be used here. Options to choose from

are Loopback, Mgmt, and VLAN.

VID

Enter the interface ID here. For loopback interfaces, the range is from 1 to 8. For

the management (Mgmt) interface, this value can only be 0. For VLAN interfaces,

the range is from 1 to 4094.

Click the Apply button to accept the changes made.

The fields that can be configured in Web Settings are described below:

Parameter Description

Web State

Select this option to enable or disable the configuration through the web.

Port

Enter the TCP port number used for Web management of the Switch. The well-

known TCP port for the Web protocol is 80.

Click the Apply button to accept the changes made.
