DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

542

Parameter Description

to be passed.

Max Users

Enter the maximum users value used here. This value must be between 1 and

4094.

Periodic

Select to enable or disable periodic re-authentication for the selected port here.

This parameter only affects the 802.1X protocol.

ReAuth Timer

Enter the re-authentication timer value here. This value must be between 1 and

65535 seconds. By default, this value is 3600 seconds.

Inactivity State

Select to enable or disable the inactivity state here. Select the Time option to

enable this feature.

Inactivity Timer

When the Inactivity State is enabled, enter the inactivity timer value here. This

value must be between 120 and 65535 seconds. This parameter only affects the

WAC authentication protocol.

Restart

Enter the restart time value used here. This value must be between 1 and 65535

seconds.

Click the Apply button to accept the changes made.

Network Access Authentication Sessions Information

This window is used to view and clear the network access authentication session information.

To view the following window, click Security > Network Access Authentication > Network Access Authentication

Sessions Information, as shown below:

Figure 9-79 Network Access Authentication Sessions Information Window

The fields that can be configured are described below:

Parameter Description

Port

Select the appropriate Switch unit and port used for the query here.

MAC Address

Enter the MAC address used here.

Protocol

Select the protocol option used here. Options to choose from are MAC, WAC,

and DOT1X.

Click the Clear by Port button to the clear the information based on the port selected.

Click the Clear by MAC button to the clear the information based on the MAC address entered.

Click the Clear by Protocol button to the clear the information based on the protocol selected.
