DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
691
Log Description Severity
Event Description: Loop back is detected under VLAN-based mode.
Log Message: IfInfo VLAN <vlanID> LBD loop occurred
Parameters Description:
IfInfo: The interface info.
vlanID: The VLAN ID number.
Critical
Event Description: Port recovered from LBD blocked state under VLAN-based mode.
Log Message: IfInfo VLAN <vlanID> LBD loop recovered
Parameters Description:
IfInfo: The interface info.
vlanID: The VLAN ID number.
Critical
Event Description: The number of VLANs that loop back has occurred hit the specified
number.
Log Message: Loop VLAN numbers overflow
Critical
LLDP-MED
Log Description Severity
Event Description: LLDP-MED topology change detected.
Log Message: LLDP-MED topology change detected (on port <portNum>. chassis id:
<chassisType>, <chassisID>, port id: <portType>, <portID>, device class: <deviceClass>)
Parameters Description:
portNum: The port number.
chassisType: chassis ID subtype.
Value list:
1. chassisComponent(1)
2. interfaceAlias(2)
3. portComponent(3)
4. macAddress(4)
5. networkAddress(5)
6. interfaceName(6)
7. local(7)
chassisID: chassis ID.
portType: port ID subtype.
Value list:
1. interfaceAlias(1)
2. portComponent(2)
3. macAddress(3)
4. networkAddress(4)
5. interfaceName(5)
6. agentCircuitId(6)
7. local(7)
portID: port ID.
deviceClass: LLDP-MED device type.
Notice
Event Description: Conflict LLDP-MED device type detected.
Log Message: Conflict LLDP-MED device type detected (on port <portNum>, chassis id:
<chassisType>, <chassisID>, port id: <portType>, <portID>, device class: <deviceClass>)
Parameters Description:
portNum: The port number.
chassisType: chassis ID subtype.
Notice
