DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

642

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

SFTP Server IP

Enter the IPv4 address of the SFTP server here.

User Name

Enter the user name used for the SFTP connection here. This name can be up to

32 characters long.

Password

Enter the password used for the SFTP connection here. This password can be up

to 15 characters long.

VRF Name

Enter the name of the VRF instance here. This name can be up to 12 characters

long.

Source File

Enter the source filename and path of the firmware file located on the SFTP

server here. This field can be up to 64 characters long.

Destination File

Enter the destination path and location where the new firmware should be stored

on the Switch. This field can be up to 64 characters long.

Click the Upgrade button to initiate the firmware upgrade.

Firmware Backup to HTTP

This window is used to initiate a firmware backup to a local PC using HTTP.

To view the following window, click Tools > Firmware Upgrade & Backup > Firmware Backup to HTTP, as shown

below:

Figure 15-7 Firmware Backup to HTTP Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

Source File

Enter the source filename and path of the firmware file located on the Switch

here. This field can be up to 64 characters long.

Click the Backup button to initiate the firmware backup.

Firmware Backup to TFTP

This window is used to initiate a firmware backup to a TFTP server.
