DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
699
Log Description Severity
alarmMsg: The alarm Msg.
PoE
Log Description Severity
Event Description: Total power usage threshold is exceeded.
Log Message: Unit <unit-id> usage threshold <percentage> is exceeded
Parameters Description:
unit-id: The box ID.
percentage: Usage threshold.
Warning
Event Description: Total power usage threshold is recovered.
Log Message: Unit <unit-id> usage threshold <percentage> is recovered
Parameters Description:
unit-id: The box ID.
percentage: Usage threshold.
Warning
Event Description: PD doesn’t reply the ping request.
Log Message: PD alive check failed. (Port: <portNum>, PD: <ipaddr>)
portNum: The port number.
ipaddr: The IP (IPv4/IPv6) address of PD.
Warning
Port
Log Description Severity
Event Description: Port linkup.
Log Message: Port <port> link up, <nway>
Parameters Description:
port: Represents the logical port number.
nway: Represents the speed and duplex of link.
Informational
Event Description: Port link down.
Log Message: Port <port> link down
Parameters Description:
port: Represents the logical port number.
Informational
Port Security
Log Description Severity
Event Description: Address full on a port.
Log Message: MAC address <mac-address> causes port security violation on <interface-
id>
Parameters Description:
macaddr: The violation MAC address.
interface-id: The interface name.
Warning
Event Description: Address full on system.
Log Message: Limit on system entry number has been exceeded
Warning
