Parameter Description

new 802.1p value in the space provided.

• Transmit - Specifies that the exceed action is to transmit the packet

unmodified.

• Set-DSCP-1P - Specifies that the exceed action is to modify the DSCP and

802.1p values and then to transmit the packet with the new DSCP and

802.1p values. Enter the new DSCP and 802.1p values in the spaces

provided.

Violate Action

Select the violate action that will be taken here. This action will be taken on red

color packets. Option to choose from are:

• None - Specifies that no violate action will be taken.

• Drop - Specifies that the violate action is to drop the packet.

• Set-DSCP-Transmit - Specifies that the violate action is to modify the DSCP

value and then to transmit the packet with the new DSCP value. Enter the

new DSCP value in the space provided.

• Set-1P-Transmit - Specifies that the violate action is to modify the 802.1p

value and then to transmit the packet with the new 802.1p value. Enter the

new 802.1p value in the space provided.

• Transmit - Specifies that the violate action is to transmit the packet

unmodified.

• Set-DSCP-1P - Specifies that the violate action is to modify the DSCP and

802.1p values and then to transmit the packet with the new DSCP and

802.1p values. Enter the new DSCP and 802.1p values in the spaces

provided.

Color Aware

Select to enable or disable the color aware feature here. When disabled, the

policer works in the color blind mode. When enabled, the policer works in the

color aware mode.

Click the Back button to return to the previous window.

Click the Apply button to accept the changes made.

Policy Binding

This window is used to display and configure the policy binding settings.
