DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

340

Parameter Description

SA Filter In

Select the Configured option and enter the SA filter-in string here. This string can

be up to 32 characters long. The router will receive all SA messages sent to it

from a specified peer. By not specifying this string, the router will ignore all SA

messages sent to it from a specified peer. By configuring this string, the router will

only receive incoming SA messages from a specified peer that matches the (S, G)

pairs defined in the standard IP access list.

SA Filter Out

Select the Configured option and enter the SA filter-out string here. This string

can be up to 32 characters long. The router will forward all SA messages to an

MSDP peer. By not specifying this string, the router will stop forwarding SA

messages to a specified peer. By specifying this string, the router only forwards

SA messages that match (S, G) pairs defined in the standard IP access list to a

specified peer.

SA Filter Request

Select the Configured option and enter the SA filter request string here. This

string can be up to 32 characters long. The router will process all SA request

messages from a specified peer. By not specifying this string, the router will stop

processing Source-Active request messages from a specified peer. By specifying

this string, the router only processes SA request messages that request groups

that are defined in the standard IP access list from a specified peer.

Minimum TTL

Enter the minimum TTL time value here. The range is from 0 to 225. When the SA

messages are sent from MSDP peers, If the Time-To-Live (TTL) value of

multicast data packets in SA message will be decreased, if the decreased TTL

value is smaller than minimum TTL value of the MSDP peer the SA message was

sent to, the SA will not be sent out.

Select the Default option to use the default value which is 0.

SA Cache Maximum

Enter the maximum SA cache value here. The range is from 0 to 8192. When the

maximum number of SA cache entries is configured to zero, the Switch cannot

learn a SA cache entry from the peer. When the maximum number of SA cache

entries is configured to be smaller than the existing SA cache entries, the older

existing SA cache entries will be removed until the number of SA cache entries is

equal to the maximum number.

Select the None option to specify that no limitation is applied for the number of

Source-Active cache entries.

Click the Back button to return to the previous window.

Click the Apply button to accept the changes made.
