User Manual

Chapter 8. Commands for EFM OAM 58

www.qtech.ru

 Packet statistic：

 Packets Send Receive

 OAMPDU 553 21

 Information 552 21

 Event Notification 1 0

 Loopback Control 0 0

 ------------------------------------------------------------------------

Field

Description

oam_status

Status of Ethernet OAM:

enable, OAM is enabled;

disable, OAM is not enabled.

local _mode

Working mode of Ethernet OAM:

active, the port is set as active mode;

passive, the port is set as passive mode.

Period

Transmission period of packets

Timeout

Timeout of connection

local_pdu

The way in which the local end processes Ethernet

OAMPDUs:

RX_INFO, the port only receives Information OAMPDUs

and does not send any Ethernet OAMPDUs.

LF_INFO, the port only sends Information OAMPDU

packets without Information TLV and with their link error

flag bits being set.

INFO, the port only sends and receives Information

OAMPDU packets.

ANY, the port sends and receives any OAMPDU packets.

local_mux_action

Working mode of the local transmitter:

FWD, the port can send any packets;

DISCARD, the port only sends OAMPDU packets and

discards others.
