User Manual
Chapter 8. Commands for EFM OAM 61
www.qtech.ru
local_mux_action
Working mode of the local transmitter:
FWD, the port can send any packets;
DISCARD, the port only sends OAMPDU packets and
discards others.
local_par_action
Working mode of the local receiver in the following:
FWD, receiving any packets is allowed;
DISCARD, only OAMPDU packets is received while others
are discarded;
LB, OAM remote loopback is enabled on the port. In this
case, all the packets except OAMPDU packets received
are returned to their sources along the ways they come.
Loopback Supported
Whether support remote loopback: YES for support and
NO for not.
Unidirectional Support
Whether support unidirectional transmission: YES for
support and NO for not.
Link Events
Whether support general link events: YES for support and
NO for not.
Remote Failure
Whether support severe link events: YES for support and
NO for not.
Max_OAMPDU_Size
The maximum length of OAMPDU is supported.
Link Fault
Whether occur a Link Fault event: 0 for no and 1 for yes.
Dying Gasp
Whether occur a Dying Gasp event: 0 for no and 1 for yes.
Critical Event
Whether occur a Critical Event: 0 for no and 1 for yes.
8.27 show ethernet-oam events
Command: show ethernet-oam events {local | remote} [interface {ethernet |}
<IFNAME>]
Function: Shows the statistic information of link events on specified or all ports with
OAM enabled, including general link events and severe link events.
