User Manual

Chapter 8. Commands for EFM OAM 60

www.qtech.ru

 Display detailed information of remote OAM entity for Ethernet 1/0/2

 Switch#show ethernet-oam remote interface ethernet1/0/2

 Ethernet1/0/2 oam remote Information：

 Remote_Mac_Address=0003.0f19.3a3e

 local _mode=active

 --------------------------------------------------------------------------

 local_pdu=INFO

 local_mux_action=FWD

 local_par_action=DISCARD

 Loopback Supported=YES

 Unidirectional Support=NO

 Link Events=YES

 Remote Failure=YES

 Max_OAMPDU_Size=1518

 --------------------------------------------------------------------------

 OAM Remote Flags Field：

 Link Fault=0 Dying Gasp=0 Critical Event=0

Field

Description

Remote_Mac_Address

MAC address of remote OAM entity

local _mode

Working mode of Ethernet OAM:

active, the port is set as active mode;

passive, the port is set as passive mode.

local_pdu

The way in which the local end processes Ethernet

OAMPDUs:

RX_INFO, the port only receives Information OAMPDUs

and does not send any Ethernet OAMPDUs.

LF_INFO, the port only sends Information OAMPDU

packets without Information TLV and with their link error

flag bits being set.

INFO, the port only sends and receives Information

OAMPDU packets.

ANY, the port sends and receives any OAMPDU packets.
