PANEL DESCRIPTION
#4 SUB•SUB OFF SWITCH [SUB•SUB OFF]
➥ Push to enable the SUB band control
from the tuning dial, keypad, etc. (p. 19)
•“SUB” indicator appears.
➥ Push for 1 sec. to turn the SUB band
readout indication ON and OFF. (p. 24)
#5 CALL•TONE SQUELCH SWITCH [CALL•T-SQL]
➥ Push to select the call channel of the op-
erating band. The call channel can be se-
lected from both the VFO and memory
mode operation. (p. 43)
➥ Push for 1 sec. to turn the tone squelch
function ON and OFF during FM mode
operation. (p. 30)
•“T-SQL” indicator appears when the tone
squelch is activated.
For 1 sec.
For 1 sec.
