Icom IC-910H [72/86] Option installations
![Icom IC-910H [72/86] Option installations](/views2/1074431/page72/bg48.png)
11
70
OPTION INSTALLATIONS
Circuitly fuse
(FGB 4 A)
Cooling fan
J1801
for UT-102
connection
SSB filter
(MAIN band)
CW-N filter
(MAIN band)
CW-N filter
(SUB band)
SSB filter
(SUB band)
MAIN unit
PLL unit
DSP unit
PLL ref. signal
(for UX-910)
DSP unit
DC power
connector
■ Internal view
• Top view — PA unit
• Bottom view — PLL/MAIN unit
