• General
• Frequency coverage : (Unit: MHz)
*
1
Optional UX-910
*
2
Guaranteed range is 144.0–148.0 MHz.
*
3
Guaranteed range is 430.0–450.0 MHz.
*
4
Guaranteed range is 1240.0–1300.0 MHz.
• Mode : USB, LSB, CW, FM, FM-N*
*Not available in 1200 MHz
• No. of memory Ch. : 212 (99 regular, 6 scan edges, 1
calls for each band)
plus 10
satellite memories)
• Antenna connector : SO-239 (50 Ω; VHF)
Type-N
(50 Ω; UHF)
• Usable temp. range : –10˚C to +60˚C;
+14˚F to +140˚F
• Frequency stability : Less than ±3 ppm
(–10 to 60˚C; +14 to +140˚F)
• Frequency resolution : 1 Hz minimum
• Power supply : 13.8 V DC ±15%
(negative ground)
• Current drain
(at 13.8 V DC; approx.)
:
Transmit Max. power 23.0 A
Receive Standby 2.0 A (3.0 A; UX-910)
Max. audio 2.5 A (3.5 A; UX-910)
• Dimensions : 241(W) × 94(H) × 239(D) mm
(projections not included) 9
1
⁄2(W) × 3
11
⁄16(H) × 9
13
⁄32(D) in
• Weight (approx.) : 4.5 kg; 10 lb
(5.35 kg; 11 lb 13 oz w/UX-910)
• ACC 1 connector : 8-pin DIN connector
• CI-V connector : 2-conductor 3.5 (d) mm (
1
⁄8″)
• DATA connectors : 6-pin mini DIN × 2
(for MAIN and SUB)
• Transmitter
• Output power (continuously adjustable):
144 MHz 5–100 W
430(440) MHz 5–75 W
1200 MHz 1–10 W (optional UX-910)
• Modulation system :
SSB Balanced modulation
FM
Variable reactance modulation
• Spurious emission :
144/430(440) MHz More than 60 dB
1200 MHz More than 50 dB
• Carrier suppression : More than 40 dB
•Unwanted sideband : More than 40 dB
suppression
•
Microphone connector
: 8-pin connector (600 Ω)
• KEY connector : 3-conductor 3.5(d) mm (
1
⁄4″)
• Receiver
• Receive system :
VHF SSB, CW
Single conversion superheterodyne
FM
Double conversion superheterodyne
UHF SSB, CW
Double conversion superheterodyne
FM Triple conversion superheterodyne
• Intermediate frequencies:
(Unit: MHz)
• Sensitivity :
SSB, CW (10 dB S/N) Less than 0.11 µV
FM (12 dB SINAD) Less than 0.18 µV
• Squelch sensitivity (threshold):
SSB, CW Less than 1.0 µV
FM Less than 0.18 µV
• Selectivity :
SSB, CW More than 2.3 kHz/–6 dB
Less than 4.2 kHz/–60 dB*
FM More than 15.0 kHz/–6 dB
Less than 30.0 kHz/–60 dB*
FM-N More than 6.0 kHz/–6 dB
Less than 18.0 kHz/–36 dB
CW-N More than 0.5 kHz/–6 dB
(w/FL-132 or FL-133) Less than 1.34 kHz/–60 dB*
*Except 1200 MHz band
• Spurious and image rejection ratio:
144/430(440) MHz More than 60 dB
1200 MHz More than 50 dB
• AF output power : More than 2.0 W at 10%
(at 13.8 V DC) distortion with an 8 Ω load
• RIT variable range :
144/430(440) MHz ±1.0 kHz (SSB, CW)
±5.0 kHz (FM)
1200 MHz ±2.0 kHz (SSB, CW)
±10.0 kHz (FM)
•
IF SHIFT variable range
: More than ±1.2 kHz
• PHONES connector : 3-conductor 6.35(d) mm (
1
⁄4″)
• Ext. SP connectors : 2-conductor 3.5 (d) mm (
1
⁄8″)
/8 Ω×2 (for MAIN and SUB)
14
80
SPECIFICATIONS
All stated specifications are typical and subject to
change without notice or obligation.
Version
144 MHz 430(440) MHz 1200 MHz*
1
U.S.A.
Tx: 144.0–148.0 Tx: 430.0–450.0 Tx: 1240.0–1300.0
Rx: 136.0–174.0*
2
Rx: 420.0–480.0*
3
Rx: 1240.0–1320.0*
4
Europe 144.0–146.0 430.0–440.0
1240.0–1300.0
Australia
144.0–148.0 430.0–450.0
1240.0–1300.0
Sweden
144.0–146.0 432.0–438.0
1240.0–1300.0
Italy 144.0–146.0
430.0–434.0
1240.0–1245.0
435.0–438.0
1270.0–1298.0
MAIN BAND SUB BAND
1st 2nd 3rd 1st 2nd 3rd
SSB
10.8500
——
10.9500
——
CW
10.8491
——
10.9491
——
FM
10.8500
0.455 —
10.9500
0.455 —
SSB
71.2500 10.8500
—
71.3500 10.9500
—
CW
71.2491 10.8491
—
71.3491 10.9491
—
FM
71.2500 10.8500
0.455
71.3500 10.9500
0.455
SSB
243.9500
10.8500
—
243.9500
10.9500
—
CW
243.9491
10.8491
—
243.9491
10.9491
—
FM
243.9500
10.8500
0.455
243.9500
10.9500
0.455
144 MHz
430(440) MHz
1200 MHz
