46
Operation Pasta Maker
1. Ensure that the function switch (7) is set to “Off” position.
2. Connect the appliance to a properly installed 230V / 50Hz
wall outlet.
3. Turn the switch (7) to turn the pasta maker with speed set-
ting 1 to 3 on.
4. Push in the dough with the pusher (18), if necessary.
Installation Mixing Container And Lid (see Fig. G)
1. Remove the cover for the mixing drive upward.
2. Hold the mixing container (32) with the handle on the right.
3. Place the mixing container on the base unit with the ▼
marking at the bottom of the container on the base unit’s
icon.
4. Turn the mixing container in the direction of the arrow until it
locks in place. ▼ and the icon must be exactly lined up.
5. Attach the lid (30) so that the ear closes the outlet.
6. Closing the inlet simultaneously arrests the lid. Place the
locking mechanism on the lid and turn towards “LOCK”
until it locks in place. Turn the locking mechanism counter-
clockwise to remove the lid.
Mixer Operation
Caution:
► For your own safety attach the mixing bowl (3) without
tools and attach the cover for the screw conveyor drive (2).
► Do not use the lever (5) for lifting/lowering the arm during
mixer operation.
► Do not exceed the MAX quantities marked on the mixing
container!
► Never ll hot or hard ingredients, such as potatoes, ice,
coffee beans, nuts, etc. into the mixing container.
Caution: Safety switch!
The appliance only operates if the ▼ and icons are
perfectly aligned.
1. Cut the ingredients into smaller pieces.
2. Fill the mixing container (32) with your ingredients (min. 0.2
l - max. 1.5 l). Do not overll!
3. Attach the lid (30).
4. Lock the lid with the locking mechanism (31).
Note:
Open the lid and/or the locking device to rell more ingredi-
ents.
► First turn the appliance off.
► Remove the lid (30) of the mixing container and ll in the
desired ingredients.
► Replace the lid on the mixing container.
Caution:
► Do not reach into the mixing container to avoid injuring on
the blade set.
► Do not operate the mixing container empty or without lid.
5. Ensure that the function switch is set to “0” position.
6. Connect the appliance to a properly installed 230V / 50Hz
wall outlet.
7. Turn the appliance on (speed setting 1 or 2 etc.) or use the
“PULSE” setting. Hold the mixing container during mixing.
For uniform mixing (continuous operation):
In speed settings 1 to 6 the switch engages in the respective
position.
Speed setting 1 = low speed
Speed setting 6 = high speed
Turn the switch to “0” position to turn the appliance off.
For pulse operation (mixing in short intervals) set the switch to
“0” position. The appliance is turned off.
• Turn the switch to “PULSE” according to the desired
interval.
• The switch automatically returns to “0” position when
released.
• Turn the mixing container counter-clockwise to remove.
• Clean all used components as described in chapter
“Cleaning”.
Cleaning
Warning:
► Always disconnect from mains power supply before
cleaning.
Caution:
► Never submerge the appliance or the motor unit in water!
► Do not use aggressive or abrasive detergents.
Motor Casing
• Clean the casing only with a damp cloth and a squirt of
washing-up liquid.
Mixing Bowl, Mixing Tools And Meat Grinder, Pasta Maker
And Mixing Container Components
Caution:
The components are not dishwasher-safe. Heat and aggres-
sive detergents will cause deformation and discoloration.
• Clean components that come into contact with foodstuffs in
sudsy water.
Warning:
The meat grinder knives are very sharp! Risk of injuries!
• Dry all components well before re-attaching to the
appliance.
• Grease the plate after drying with a squirt of vegetable oil.
