Hitachi DS12DVF3-TB [8/58] English

English

CAUTION

䡬 The selection examples shown in Table 4 should

be considered as general standard. As different

types of tightening screws and different materials

to be tightened are used in actual works proper

adjustments are naturally necessary.

䡬 When using the driver drill with a machine screw

at HIGH (high speed), a screw may damage or a

bit may loose due to the tightning torque is too

strong. Use the driver drill at LOW (low speed)

when using a machine screw.

6. Mounting and dismounting of the bit

(1) After inserting a driver bit, etc. into the keyless drill

chuck, firmly grasp the ring and tighten the sleeve

by turning it toward the right (in the clockwise

direction as viewed from the front) (See Fig. 9).

䡬 If the sleeve becomes loose during operation, tighten

it further. The tightening force becomes stronger

when the sleeve is tightened additionally.

(2) Dismounting the bit

Firmly grasp the ring and loosen the sleeve by

turning it toward the left (in the counter-clockwise

direction as viewed from the front) (See Fig. 9).

CAUTION

䡬 When it is no longer possible to loosen the sleeve,

use a vise or similar instrument to secure the bit.

Set the clutch mode between 1 and 11, and then

turn the sleeve to the loose side (left side) while

operating the clutch. It should be easy now to

loosen the sleeve.

7. Confirm that the battery is mounted correctly

8. Check the rotational direction

The bit rotates clockwise (viewed from the rear

side) by pushing the R-side of the selector button.

The L-side of the selector button is pushed to turn

the bit counterclockwise (See Fig. 10) (The

and

marks are provided on the body).

9. Switch operation

䡬 When the trigger switch is depressed, the tool

rotates. When the trigger is released, the tool stops.

䡬 The rotational speed of the drill can be controlled

by varying the amount that the trigger switch is

pulled. Speed is low when the trigger switch is

pulled slightly and increases as the trigger switch

is pulled more.

NOTE

䡬 A buzzing noise is produced when the motor is

about to rotate; This is only a noise, not a machine

failure.

10. Using the hook

CAUTION

䡬 When using the hook, pay sufficient attention so

that the main equipment does not fall. If the tool

falls, there is a risk of accident.

䡬 Do not attach the tip tool except phillips bit to the

tool main unit when carrying the tool main unit with

the hook suspended from a waist belt.

Injury may result if you carry the equipment

suspended from the waist belt with sharp tipped

components such as drill bit attached.

The hook can be installed on the right or left side and

the angle can be adjusted in 5 steps between 0° and

80°.

(1) Operating the hook

(a) Pull out the hook toward you in the direction

of arrow (A) and turn in the direction of arrow

(B) (Fig. 11).

(b) The angle can be adjusted in 5 steps (0°, 20°,

40°, 60°, 80°).

Adjust the angle of the hook to the desired

position for use.

(2) Switching the hook position

CAUTION

Incomplete installation of the hook may result in

bodily injury when used.

(a) Securely hold the main unit and remove the

screw using a slotted head screwdriver or a coin

(Fig. 12).

(b) Remove the hook and spring (Fig. 13).

securely fasten with screw (Fig. 14).

NOTE

Pay attention to the spring orientation. Install the

spring with larger diameter away from you (Fig. 14).

(3) Using the bit holder (Hook with bit holder)

䡬 Installing the bit

Slide the bit from the side and then insert firmly

until the groove on the bit locks in the protruded

section of the hook.

5. How to select tightening torque and rotational speed

Table 4

Use

Clutch Dial

Rotating speed selection (Position of the shift knob)

Position

LOW (Low speed) HIGH (High speed)

Machine screw 1 – 22

For 4 mm or smaller diameter

screws.

Driving

Wood screw 1 –

For 5.8 mm or smaller nominal

diameter screws.

Drilling

Wood

For 25 mm or smaller

diameters. (DS12DVF3)

For 21 mm or smaller

diameters. (DS9DVF3)

Metal

For drilling with a metal

working drill bit.

For 6 mm or smaller

diameter screws.

For 3.8 mm or smaller

nominal diameter screws.

For 12 mm or smaller

diameters.
