Aten CS724KM [13/99] Introduction

Chapter 1

Introduction

Overview

The CS724KM is a 4-port USB KM Switch that enables users to control up to

4 computers with a single keyboard and mouse. Two switches can be daisy-

chained to enable control of up to 8 computers from a single console.

The CS724KM features various innovative port selection methods. Users can

switch between the connected computers via front panel pushbutton, keyboard

hotkey, mouse cursor, mouse wheel, and RS-232 commands. The mouse

cursor method adopts ATEN’s exclusive Boundless Switching technology,

which provides an intuitive way to switch control to another computer by

simply moving your mouse cursor across a screen border and onto the target

computer display. Move the mouse cursor in any direction to switch the control

focus without limitations.

The CS724KM’s Boundless Switching function supports extended desktops

with up to sixteen monitors total, expediting the process of switching between

computers for a smooth and hassle-free user experience. In addition to making

multitasking across multiple displays more efficient, this function is especially

useful in emergencies that necessitate the immediate monitoring and

management of computers.

The CS724KM also provides an intuitive GUI-based configuration utility that

allows users to customize their mouse cursor movement paths according to the

specific monitor layout at the desktop or workstation. The configuration tool is

easy to set up and compatible with Windows operating systems.

Further advanced features of the CS724KM include bus-power mode which

means no external power adapter is required, as well as independent switching

of the keyboard/mouse, USB peripheral, and audio focus via hotkeys. With a

rich feature set, the CS724KM is designed to simplify administrative tasks,

save space, and increase work productivity in multi-monitor extended desktop

environments, and is especially suitable for complex multitasking applications

in control rooms in any industry.
