Aten CS724KM [32/99] Cycling through the ports

CS724KM User Manual

Cycling Through the Ports

Hotkey Action

[Scroll Lock] [Scroll Lock]

[Enter]

Brings the KM, USB hub, and audio focus from the port

that currently has it to the next port on the installation (1

to 2; 2 to 3; 3 to 4; 4 to 1). The KM, USB hub, and audio

focus all go to this port even if they were on different

ports to begin with.

Example:

1. Press [Scroll Lock] twice.

2. Press [Enter].

[Scroll Lock] [Scroll Lock]

[K] [Enter]

Brings only the KM focus from the port that currently has

it to the next port on the installation. The USB hub and

audio focus remain where they are.

Example:

1. Press [Scroll Lock] twice.

2. Press [K].

3. Press [Enter].
