CS724KM User Manual
28
Mouse Emulation
To toggle between mouse emulation enabled and disabled, do the following:
1. Invoke HSM (see page 24
).
2. Press [M].
This procedure is a toggle. Repeat to revert to the original setting
Note: This hotkey operation will be disabled under daisy chain
installation.
Mouse Port Switching
Mouse Port Switching allows you to use the mouse wheel button (clicked
twice) to switch ports. For Mouse Port Switching to work, Mouse Emulation
(above) must be enabled. To toggle between mouse port switching enabled and
disabled, do the following:
1. Invoke HSM (see page 24
).
2. Press [W].
This procedure is a toggle. Repeat to revert to the original setting.
Note: 1. This feature is only supported by USB 3-key scroll wheel mice.
The default setting is disabled. This feature is only supported
when mouse emulation is also enabled. See Mouse Emulation,
above.
2. This hotkey operation will be disabled for a secondary CS724KM
under daisy chain installation.
Keyboard Emulation
The console keyboard port emulation/bypass feature supports most gaming/
multimedia keyboards. The default setting is enabled. To disable, do the
following:
1. Invoke HSM (see page 24).
2. Press [N].
This procedure is a toggle. Repeat to revert to the original setting.
Note: 1. When keyboard emulation is disabled, the [M], [Q], [W], [F2],
[F4], [F5], [F6], and [F10] hotkey operations are disabled.
2. This hotkey operation will be disabled under daisy chain
installation
