CS724KM User Manual

Keyboard Operating Platform

The switches’ default port configuration is for a PC-compatible keyboard

operating platform. To enable / disable windows keyboard emulation:

1. Bring the KM focus to the port you want to set.

2. Invoke HSM (see page 24).

3. Press and release the Function key (see table below). After completing this

procedure, you automatically exit HSM.

Note: When the Driver AP is turned on, the [F1], [F2], [F3], and [F10] hotkey

operations are disabled.

List Switch Settings

To see a listing of the current switch settings, do the following:

1. Open a text editor or word processor and place the cursor in the page

window.

2. Invoke HSM (see page 24).

3. Press and release [F4] to display the settings.

USB Reset

If the USB loses focus and needs to be reset, do the following:

1. Invoke HSM (see page 24).

2. Press and release [F5].

Function Key Operation

[F1] Sets the SPC mode so that it can work under special

operating systems as a standard (104 key) keyboard.

[F2] Enables Mac keyboard emulation, see page 39, for details.

[F3] Enables Sun keyboard emulation, see page 40, for details.

[F10] Enables Windows keyboard emulation.
