Chapter 8. RS-232 Commands

USB Reset

The USB Reset command allows you to reset the USB connections.

The formula for USB Reset commands is as follows:

Command + Input Command + [Enter]

To reset the USB connections, type the following:

usbreset on [Enter]

The tables show the values for the USB Reset commands.

Command Description

usbreset USB Reset command

Input Command Description

on Enable USB reset connection

Enter Description

[Enter] Send command
