Aten CS724KM [33/99] Switching the ports with mouse cursor
![Aten CS724KM [33/99] Switching the ports with mouse cursor](/views2/1977310/page33/bg21.png)
Chapter 4. Hotkey Operation
21
Switching the Ports with Mouse Cursor
[Scroll Lock] [Scroll Lock]
[K] [U] [Enter]
Brings the KM and USB hub focus from the port that
currently has it to the next port on the installation with
the mouse cursor. The audio focus remains where it is.
Example:
1. Press [Scroll Lock] twice.
2. Press [K], and then press [U].
3. Press [Enter].
[Scroll Lock] [Scroll Lock]
[K] [S] [Enter]
Brings the KM and audio focus from the port that
currently has it to the next port on the installation with
the mouse cursor. The USB hub focus remains where it
is.
Example:
1. Press [Scroll Lock] twice.
2. Press [K], and then press [S].
3. Press [Enter].
[Scroll Lock] [Scroll Lock]
[K] [K] [Enter]
Brings only the KM focus from the port that currently has
it to the next port on the installation with the mouse
cursor. The USB hub and audio focus remains where it
is.
Example:
1. Press [Scroll Lock] twice.
2. Press [K], and then press [K].
3. Press [Enter].
