Aten CS724KM [97/99] Specifications
![Aten CS724KM [97/99] Specifications](/views2/1977310/page97/bg61.png)
Appendix
85
Specifications
* Port switching only works with 3-key USB mouse wheel in emulation mode.
Function CS724KM
Computer
Connections
Direct 4
Max 8 via Daisy Chain
Port Selection Pushbuttons, Hotkeys, Mouse Wheel*, Mouse Cursor,
RS-232 Commands
Connectors Console
Ports
Keyboard 1 x USB Type A Female (Black)
Mouse 1 x USB Type A Female (Black)
Speakers 1 x 3.5 mm Audio Jack Female (Green; Front)
1 x 3.5 mm Audio Jack Female (Green; Rear)
KM Ports KB /
Mouse
4 x USB Type B Female (Black)
Speakers 4 x 3.5 mm Audio Jack Female (Green)
USB Hub 1 x USB Type A Female (Black; Front)
1 x USB Type A Female (Black; Rear)
Daisy Chain / Serial 1 x RJ-45 Female
Power 1 x DC Jack
Switches Port Selection 4 x Pushbutton
Station Selection 1 x Slide Switch
LEDs Selected 4 (Green)
Emulation Keyboard / Mouse USB
Power Consumption DC5V:1.69 W:33BTU
Environment Operating Temp. 0–50º C
Storage Temp. -20–60º C
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal, Plastic
Weight 0.5 kg (1.1 lb)
Dimensions (L x W x H) 20.00 x 8.06 x 2.50 cm (7.87 x 3.17 x 0.98 in)
