Appendix
83
Troubleshooting
Operation problems can be due to a variety of causes. The first step in solving
them is to make sure that all cables are securely attached and seated completely
in their sockets.
In addition, updating the product’s firmware may solve problems that have
been discovered and resolved since the prior version was released. If your
product is not running the latest firmware version, we strongly recommend that
you upgrade. See The Firmware Upgrade Utility, page 59, for upgrade details.
Symptom Possible Cause Action
Erratic behavior. Unit not receiving
enough power.
Use a DC 5V power adapter if you
are not already using one. If you are
already using a power adapter,
check that it matches the system
specifications, and that it is plugged
in and functioning properly.
Keyboard and/or
mouse need to be
reset.
Unplug the cable(s) from the console
port(s), then plug it/them back in.
No connection to the
computer.
Check the cable from the switch to
the computer to make sure it is
properly connected.
KM switch needs to
be reset.
Power off all devices on the
installation; power off the KM switch;
wait five seconds; then power up.
USB devices not
responding.
USB ports need to be
reset.
Unplug the device’s USB cable from
the USB port on the switch’s rear
panel, then plug it back in.
Use the USB Reset hotkey
combination (see page 26), to reset
the USB ports.
Boundless switching
is abnormal.
Commonly behavior
for the KVM switch to
switch port before
mouse cursor
reaching the edge of
the display.
Define each port video resolution by
utilizing utility from the Boundless
Switching Utility, see Resolution,
page 56.
Go to Mouse Properties from your
PC system settings.
1. Disable Mouse acceleration.
2. Disable Enhance the pointer
precision.
