Aten CS724KM [89/99] Firmware upgrade

Chapter 8. RS-232 Commands

Firmware Upgrade

The Firmware Upgrade command allows you to enable firmware upgrade

mode.

The formula for Firmware Upgrade commands is as follows:

Command + Input Command + [Enter]

To enable firmware upgrade mode, type the following:

upgrade on [Enter]

The tables show the values for the Firmware Upgrade commands.

Command Description

upgrade Firmware Upgrade command

Input Command Description

on Enable firmware upgrade mode

Enter Description

[Enter] Send command
