19
Chapter 4
Hotkey Operation
The switch provides an extensive, easy-to-use, hotkey function that makes it
convenient to control and configure your KM installation from the keyboard.
Hotkeys also provide asynchronous independent switching of the keyboard/
mouse, USB hub, and audio focus. Therefore, you can give one computer the
keyboard/mouse focus, another the USB hub focus, while a third has the audio
focus.
Port Switching
All port switches begin with tapping the [Scroll Lock] key twice. The tables
below describe the actions that each key combination performs.
Note: 1. If using the [Scroll Lock] key conflicts with other programs running
on the computer, the [Ctrl] key can be used, instead. See Alternate
Port Switching Keys, page 25, for details.
2. With firmware v1.1.106 or earlier, the port switching will be disabled
for extended desktops boundless switching when the Driver AP is
running. For full functioning of the port switching, upgrade the
firmware to v1.1.107 or later.
