Chapter 4. Hotkey Operation

Example 5:

2 x 3 Monitor Layout

No Monitors 1st & 3rd Slot of Row A

Keep Awake Option

To keep the connected computers awake from sleep mode, do the following:

1. Invoke HSM (see page 24).

2. Press [I] [n] [Enter].

Note: n is an number that represents a keep awake option.

 n = 1, the connected computers always stay on.

 n = 2, the connected computers stay on while being operated.

Press: PA010B234 [Enter]

Monitor #

10 0
