Aten CS724KM [15/99] Requirements

Chapter 1. Introduction

6. It is required to download and install the Driver AP software on

the connected computers for extended desktops boundless

switching to work.

7. The USB bus-powered design allows the switch to get power

from the connected computers. It requires connection to at least

two computers to get sufficient power supply.

Requirements

Console

 A USB mouse

 A USB keyboard

 Speakers

Computers

The following equipment must be available on each computer:

 Video Display

 USB Type-A port

 Audio ports

Operating Systems

Note: The CS724KM is only compatible with Linux 64 bit operating system.

OS Version

Windows 7 / 10 and higher

Linux Cent OS 7.0 and higher

Ubuntu 16.0 and higher

Red Hat

Enterprise

7.0 and higher

Kylin OS 7.0

Linx 6.0.80

Astra Linux 2.12
