Aten CS724KM [83/99] Switch port

Chapter 8. RS-232 Commands

Switch Port

The Switch Port command allows you to switch ports.

The formula for Switch Port commands is as follows:

Command + Input Command + [Enter]

To switch to the computer connected to port 04, type the following:

sw i04 [Enter]

To switch to the computer connected to port 01, type the following:

sw i01 [Enter]

The tables show the values for the Switch Port commands.

Note: With firmware v1.1.106 or earlier, the switch port will be disabled when

the Driver AP is running. For full functioning of the switch port,

upgrade the firmware to v1.1.107 or later.

Command Description

sw Switch ports

Input Command Description

ixx Switch to input port number:

xx=01~04

Enter Description

[Enter] Send command
