Aten CS724KM [86/99] Hotkey switching

CS724KM User Manual

Hotkey Switching

The Hotkey Switching command allows you to change the hotkey switching

mode.

The formula for Hotkey Switching commands is as follows:

Command + Input Command + [Enter]

To change the hotkey switching mode to [Ctrl] + [Ctrl], type the following:

switch scroll [Enter]

To change the hotkey switching mode to [Num Lock] + [-], type the following:

switch ctrl [Enter]

The tables show the values for the Hotkey Switching commands.

Command Description

switch Hotkey Switching command

Input Command Description

scroll Change the hotkey switching

mode to:

[Scroll Lock] [Scroll Lock]

(default setting)

ctrl Change the hotkey switching

mode to: [Ctrl] [Ctrl]

Enter Description

[Enter] Send command
