CS724KM User Manual

4 station

switch

The station switch sets the function of the CS724KM. The

default position for normal operation is P. The S position is

utilized when an RS-45 cable is connected to the serial port

and can be used for two separate functions:



Slide the switch to the S position to send RS-232

commands to the unit (see page 65); or



Slide the switch to the S position on the second stage unit

in a daisy chain installation (see page 12). The first stage

unit in a daisy chain installation should be set to P.

5 port LEDs The four port LEDs are built into the front panel.



Lights green to indicate that the computer attached to its

corresponding port is the one that has the keyboard /

mouse, USB hub and audio focus.



Flashes green once every 0.5 seconds to indicate that the

CS724KM is running with insufficient power supply.

No. Component Description
