CS724KM User Manual

6. (Optional) Plug your USB peripherals into the USB Type-A ports located

on the unit’s front and rear panel.

7. (Optional) Plug an RJ-45 cable to the serial port to use RS-232 commands

to control the switch (see RS-232 Commands, on page 65).

8. (Optional) Plug a power adapter into the switch’s power jack and then plug

the other end into an AC power source.*

Note: A power adapter is not provided with the package as the USB bus-

power allows the switch to get power from the computers. It requires

connection to at least two computers to get a sufficient power

supply.

9. Power on the computers.

Note: Make sure the computers and devices that the CS724KM connects

to are also properly grounded.
