CS724KM User Manual
48
Item Description
File Click to open the File menu:
New: clears all Displays allowing you to create a new
layout.
Load File: opens a browse window to select and load
a previously created Layout (*.KM) file.
Save as: opens a browse window to save the current
layout (*.KM) file.
Quit: closes the Boundless Switching Configuration
Utility.
Settings Click to open the Settings menu:
Mouse Acceleration: sets the rate at which the cur-
sor speed increases as the speed of the cursor moves
faster across the display.
Mouse Position: sets the default cursors position for
when you switch from one computer to another. When
the mouse cursor leaves to switch to another com-
puter, the cursor on the previous computer will auto-
matically move to this position on the monitor.
Boundless Switching Focus: disable/enable, and
sets a duration for the boundless switching focus from
3, 5, 10 seconds, or always.
Note: This setting is only available with Boundless
Switching Configuration Utility version v1.0.068 or
higher.
Keep Awake Option: disable or sets an option
between always and while working to keep the com-
puter awake from sleep mode.
Note: This setting is only available with Boundless
Switching Configuration Utility version v1.0.068 or
higher.
Click the Add icon over empty blocks to add a new
display. After adding a display you are prompted to enter
the screen resolution of the display. It is important that
the resolution setting is correct (see Resolution, below).
After setting the resolution a Display icon appears. Add
icons to match the physical monitor setup of your
installation.
