CS724KM User Manual

4. After adding Display icons to represent the physical monitor setup, use the

drop-down menu of each Display to set the port.

In a Single Stage Installation (page 9) choose option: P1, P2, P3, P4, or no

port.

In a Daisy Chain Installation (page 12) choose options according to the

Station Switch – Primary: P1, P2, P3, P4; or Secondary: S1, S2, S3, S4.

5. Click Save to local to save the layout configuration file to disk; or Save to

device to upload and apply the layout to the CS724KM.
