CS724KM User Manual

4. Connect the USB Type-A connector to a USB Type-A port on the

computer.

5. Press and hold port selection pushbutton 1.

6. While holding port selection pushbutton 1, connect the USB Type-B

connector into PC port 1. The four front panel LEDs all flash together to

indicate Firmware Upgrade Mode is in effect.

You can also connect a keyboard to the console port and invoke the

firmware upgrade mode via hotkey (see Firmware Upgrade Mode,

page 27).

Note: The USB cable's USB Type-B connector can be connected to any KM

port section, but the Port Selection pushbutton in Step 5 must be Port 1.
