98
The PSR-4000 “Functions”
The PSR-4000 [FUNCTION] button selects 8 groups of functions
that access a number of related parameters. Here’s a list of the func-
tions and the manual page numbers on which they are described in
detail.
[F1] SCALE (ARABIC)/VOICE PART ..................................................100
[F2] SPLIT POINT/ABC MODE/MULTI PAD .......................................102
[F3] CONTROLLER .............................................................................104
[F4] STYLE REVOICE..........................................................................108
[F5] REVERB/CHORUS/DSP EFFECT ...............................................110
[F6] HARMONY/REGISTRATION........................................................114
[F7] UTILITY .........................................................................................115
[F8] MIDI ...............................................................................................116
General Function Selection & Editing Procedure
Press the [FUNCTION] button to engage the function mode.
SONG
PLAY
CUSTOM
VOICE EDIT
FUNCTION
SONG
RECORD
CUSTOM
ACCOMP. REC
DISK
Each of the function groups is selected by press-
ing the corresponding LCD button. In some cases all
of the parameters included in a function group will
be available in a single display “page”, and the
various parameters can be accessed via the ▲ and ▼
LCD buttons — as in the F3: CONTROLLER dis-
play, below.
