![Yamaha PSR-4000 [136/165] Setup parameters setup parameter paramètres de réglage général parámetros de ajuste](/img/pdf.png)
Yamaha PSR-4000 [136/165] Setup parameters setup parameter paramètres de réglage général parámetros de ajuste
![Yamaha PSR-4000 [136/165] Setup parameters setup parameter paramètres de réglage général parámetros de ajuste](/views2/2009444/page136/bg88.png)
132
REGISTRATION
ONE TOUCH DISK DATA MEMORY RECALL FACTORY
REGISTRATION
FREEZE
SETTING group BACK UP group name PRESET
group name
O.T.S.
NUMBER for each style X — X SETUP OX1
TEMPO SET ON/OFF X — X SETUP OXON
F1
SCALE
SCALE O SCALE O SETUP OXEQUAL TEM-
PERAMENT
TUNE (NOTE:C) O SCALE O SETUP O SCALE 0
TUNE (NOTE:Db) O SCALE O SETUP O SCALE 0
TUNE (NOTE:D) O SCALE O SETUP O SCALE 0
TUNE (NOTE:Eb) O SCALE O SETUP O SCALE 0
TUNE (NOTE:E) O SCALE O SETUP O SCALE -50
TUNE (NOTE:F) O SCALE O SETUP O SCALE 0
TUNE (NOTE:F#) O SCALE O SETUP O SCALE 0
TUNE (NOTE:G) O SCALE O SETUP O SCALE 0
TUNE (NOTE:Ab) O SCALE O SETUP O SCALE 0
TUNE (NOTE:A) O SCALE O SETUP O SCALE 0
TUNE (NOTE:Bb) O SCALE O SETUP O SCALE 0
TUNE (NOTE:B) O SCALE O SETUP O SCALE -50
VOICE PART
PART TUNE MODE O VOICE O SETUP OXAUTO
TUNE (LEAD) O VOICE O SETUP OX+3cent
TUNE (RIGHT1) O VOICE O SETUP OX0cent
TUNE (RIGHT2) O VOICE O SETUP OX-3cent
TUNE (LEFT) O VOICE O SETUP OX0cent
OCTAVE (LEAD) O VOICE O SETUP OX0
OCTAVE (RIGHT1) O VOICE O SETUP OX0
OCTAVE (RIGHT2) O VOICE O SETUP OX0
OCTAVE (LEFT) O VOICE O SETUP OX0
PAN (LEAD) O VOICE O SETUP OXCENTER
PAN (RIGHT1) O VOICE O SETUP OXCENTER
PAN (RIGHT2) O VOICE O SETUP OXCENTER
PAN (LEFT) O VOICE O SETUP OXCENTER
F2
SPLIT POINT (ABC) O ACCOMP. O SETUP OXF#2/G2
SPLIT POINT (LEFT) O VOICE O SETUP OXF#2/G2
ABC MODE O ACCOMP. X SETUP OXFINGERED 1
AUTO MUTE O ACCOMP. X SETUP OXON
MANUAL MIDI BASS VOICE O ACCOMP. X SETUP OXAcousticBass
M.PAD REPEAT O MULTI PAD X SETUP OXPHRASE: OFF,
CHORD: ON
M.PAD CODE MATCH O MULTI PAD X SETUP OXM.PAD1/2:OFF,
M.PAD3/4:ON
F3
FOOT VOLUME TYPE O CONTROLLER X SETUP OXMASTER
FOOT VOLUME ASSIGN O CONTROLLER X SETUP OXALL ON
FOOT SW1 TYPE O CONTROLLER X SETUP OXSUSTAIN
SUSTAIN ASSIGN for O CONTROLLER O SETUP OXALL ON
FOOT SW1/2,
SUSTAIN BUTTON
SOSTENUTO ASSIGN for O CONTROLLER X SETUP OXALL ON
FOOT SW1/2
SOFT ASSIGN for O CONTROLLER X SETUP OXALL ON
FOOT SW1/2
PERCUSSION for O CONTROLLER X SETUP OX
01 STANDARD KIT/
FOOT SW1 37 CrashCy1
FOOT SW2 TYPE O CONTROLLER X SETUP OXROTARY SP
PERCUSSION for O CONTROLLER X SETUP OX
01 STANDARD KIT/
FOOT SW2 24 Kick H
PITCH BEND WHEEL O CONTROLLER O SETUP OXALL ON
ASSIGN
MODULATION WHEEL O CONTROLLER O SETUP OXALL ON
ASSIGN
INITIAL TOUCH SENS. O CONTROLLER O SETUP OXNORMAL
INITIAL TOUCH ASSIGN O CONTROLLER O SETUP OXALL ON
INITIAL TOUCH OFF LEVEL O CONTROLLER O SETUP OX64
Setup Parameters • Setup-Parameter • Paramètres de réglage général • Parámetros de ajuste
