92
Disk Operations
Save To Disk
NOTES
• If an unformatted disk or a disk which has not been
formatted for use with the PSR-4000 is inserted, the
“Wrong disk type or format! Format disk?” confirmation
message will appear when the SAVE TO DISK function is
selected. Press YES to format the disk or NO to cancel.
If the FILE LIST display shown to the right is
not showing, press the LIST LCD button to select it.
Use FILE LCD [▲/▼] controls to select the file to
which you want to save the data. The file list at the
bottom of the display includes all files which cur-
rently exist on the disk and one “*** NEW ***”
file. Select an existing file if you want to overwrite
the file with the new data, or select the “*** NEW
***” file if you want to create a new file. With the
exception of the “*** NEW ***” file, the size of
each file will appear to the right of the file name in
kilobytes (approximate).
If you want to specify the type(s) of data to be
saved, press the PROGRAM LCD button.
The ▲ and ▼ LCD buttons to the left of the
display can now be used to select various groups of
data, and the LCD [▲/▼] controls can be used to
select the individual type(s) of data to be saved to the
selected file. Data types which are turned ON are
saved.
SETUP All setup data — see list on page 131.
STYLE REVOICE All STYLE REVOICE settings - page 108.
MULTI PAD All MULTI PAD phrase, percussion, and chord data - page 36.
REGISTRATION BANK The ▲ and ▼ LCD buttons select REGISTRATION memory bank groups 1… 8 and 9 …
16. The LCD [▲/▼] controls turn the individual banks within the selected group ON or OFF.
CUSTOM STYLE The ▲ and ▼ LCD buttons select CUSTOM STYLE memory groups 1… 8 or 9…12. The
LCD [▲/▼] controls turn the individual custom style within the selected group ON or OFF.
CUSTOM VOICE The ▲ and ▼ LCD buttons select CUSTOM VOICE memory groups 1… 8, 9 … 16, 17 …
24, or 25 … 32. The LCD [▲/▼] controls turn the individual custom voice within the se-
lected group ON or OFF.
SONG SETUP Determines whether the above data will be loaded before song playback is started in the
SONG PLAY mode.
Saves the data listed below to a floppy disk inserted into the PSR-4000 disk drive.
