59
Song Playback & Recording
Quick Record Mode Edit Functions
The QUICK RECORD mode EDIT display includes only one function: SONG DELETE.
Select the EDIT display via the [
] LCD button to the right of the display.
■ SONG DELETE...............................................................................................................................................................................
This function deletes the specified song file from the disk.
NOTES
• The song currently being recorded cannot be deleted.
• The amount of remaining disk space is displayed in the
upper right corner of the display in approximate kilobytes
while recording or playback is stopped.
ZSelect a Song
Use the SONG LCD [▲/▼] controls to select the
song to be deleted.
XDelete the Song
Press the EXECUTE LCD button. The “Ready to
Delete ********. OK to delete?” confirmation
message will appear (“********” is the song name).
Press YES to delete the song or NO to cancel.
