73
Custom Accompaniment
[ Go On to EFFECTS, EDIT, and STORE ................................................................................................................
You can now stop the accompaniment by press-
ing the [START/STOP] button (or leave it running,
as required), and go on to the EFFECTS and EDIT
functions described below. When your custom ac-
companiment is complete, be sure to use the STORE
function, also described below, to store the style to
one of the CUSTOM memory locations.
Exit When Done.............................................................................................................................................................................
When your custom accompaniment is complete,
press the [CUSTOM ACCOMP. REC] or [EXIT]
button to exit from the CUSTOM ACCOMPANI-
MENT RECORD mode.
Effects
Select the EFFECTS display via the [ ] or [ ] LCD button to the right of the display. If not already selected,
press the SETTING LCD button to access the REVERB DEPTH, CHORUS TYPE/DEPTH, and PAN parameters for
the current section.
■ REVERB DEPTH...........................................................................................................................................................................
Use the ▲ and ▼ buttons to the left of the display
to select the REVERB DEPTH parameters, then use
the RHY1, RHY2, BASS, CHD1, CHD2, PAD,
PHR1, and PHR2 LCD [▲/▼] controls to set the
reverb depth for the corresponding parts.
SONG
PLAY
CUSTOM
VOICE EDIT
FUNCTION
SONG
RECORD
CUSTOM
ACCOMP. REC
DISK
EXIT
