9
The Random & Single Demo Play Modes
If you play the demo as described above, you’ll hear all 14 demo songs played in random order. By selecting
an appropriate play mode you can also play back all the songs sequence, or play a single specified song.
The Demonstration
Z
Select a Play Mode ....................................................................................................................................................................
Use either of the LCD [▲/▼] controls under
MODE on the display to select one of the available
play modes.
ALL All 14 demo songs are played
back in sequence.
RANDOM All 14 demo songs are played back
in random order. This is the default
mode.
SINGLE SONG Only the selected song is played.
X Select a Song .........................................................
Press the LCD button corresponding to the type
of demo song you want to play, then use the same
LCD button to select either of the two demo songs
in that group. You can also use either of the LCD [▲/
▼] controls under SONG on the display to select any
of the 14 demo songs.
V Start & Stop Playback as Required.........................................................................................................................
Press the START LCD button to start playback of
the selected demo song(s). Press the STOP LCD
button when you want to stop playback.
C Turn the Repeat Mode ON or OFF.............................................................................................................................
Use the REPEAT LCD [▲/▼] control to turn
repeat playback ON or OFF as required (when ON,
the selected song or sequence of songs will be
repeated until the STOP LCD button is pressed)
B Exit When Done ............................................................................................................................................................................
Press either the [DEMO] button or the [EXIT]
button to exit from the demo mode and return to the
normal play-mode display when you’ve finished
playing the demo songs.
DEMO
EXIT
