48
■ Pause, Fast Forward & Reverse..................................................................................................................................
When you press the STOP [■] LCD button,
playback stops and the song position returns to the
beginning of the song. The PAUSE LCD button,
however, lets you pause playback and then start
again from the same point in the song. Playback can
be restarted either by pressing the PAUSE LCD
button again or by pressing the START LCD button.
While the PAUSE mode is engaged the F.F.
[f] (Fast Forward) and REW [r] (Reverse) LCD
buttons rapidly move the playback location forward
and backward in 1-measure steps, respectively. The
[r] and [f] buttons can be used both during
playback and while playback is paused. The REW
[r] LCD button will not appear and reverse opera-
tion will not be possible when a GM song disk (SMF
Format 1) is being played.
C Select a Play Mode ....................................................................................................................................................................
Also, use the REPEAT LCD [▲/▼] control to
turn the repeat mode ON or OFF as required. When
ON, playback will repeat continuously until stopped.
V Start/Stop Playback..................................................................................................................................................................
Press the START LCD button to start playback.
Playback will stop automatically when the specified
song(s) have been played all the way through (un-
less the repeat mode is ON). You can also stop
playback at any time by pressing the STOP [■] LCD
button.
Song Playback & Recording
Use the MODE LCD [▲/▼] controls to select a
play mode:
SINGLE Plays the single song selected via
the SONG SELECT controls.
ALL Plays all songs in the song list in
order.
CHAIN Plays the songs specified in the
CHAIN LIST in the specified order.
Set this via the MAKE CHAIN button.
RANDOM Plays all songs in the song list in
random order.
