13
Playing the PSR-4000
Z Set Initial Volume Levels .....................................................................................................................................................
Set the [MASTER VOLUME] control to an
appropriate level, and make sure that the LEFT, R1,
R2, LEAD volume levels in the MIXER MAIN
VOLUME display are set to their maximum “100”
levels (use the corresponding LCD [▲/▼] controls
to set these volume levels if necessary). You can set
the [MASTER VOLUME] control for the most
comfortable overall volume level after beginning to
play.
NOTES
• No sound will be produced if all volume levels other than
the [MASTER VOLUME] control are set to their minimum
values.
MASTER VOLUME
MIN •• MAX
X Select the Orchestra Parts You Want To Play................................................................................................
Press the [RIGHT 1], [RIGHT 2], [LEAD], and/or [LEFT] button(s), turning on the
indicators corresponding to the parts you want to play.
Each time you turn a part on or off, the EASY SETTING LCD button for that part will
appear on the LCD for a few seconds.
R 1
R 2
PIANO
ORGAN
STRINGS/
CHOIR
SAX/
WOODWIND
TRUMPET/
BRASS
GUITAR/
BASS
RIGHT 1
ACCORDION/
WORLD
SYNTH/
PAD
SOUND
EFFECT
PERCUSSIVE
DRUM KIT
CUSTOM
VOICE
PART SELECT
RIGHT ORCHESTRA
RIGHT 2
TRUMPET/
BRASS
SAX/
WOODWIND
STRINGS/
CHOIR
GUITAR/
BASS
SYNTH/
PERCUSSIVE
CUSTOM
VOICE
LEAD
LEAD
PIANO/
ORGAN
STRINGS/
CHOIR
BRASS/
WOODWIND
SYNTH/
PA D
GUITAR/
PERCUSSIVE
CUSTOM
VOICE
LEFT ORCHESTRA
LEFTLEFT HOLD
