47
Song Playback & Recording
Song Playback
The PSR-4000 SONG PLAY mode allows song data to be played back from a floppy disk. The song file types
which can be played by the PSR-4000 are: songs recorded on the PSR-4000, DOC (Disk Orchestra Collection),
Disklavier and GM song (SMF format). Refer to the DOC or SMF disk manuals as necessary.
Z Insert a Song Disk......................................................................................................................................................................
Insert a song disk into the PSR-4000 disk drive
— a disk containing songs you have recorded on the
PSR-4000 yourself, a Yamaha DOC (Disk Orchestra
Collection), a Yamaha Disklavier disk, or a GM
song disk. The SONG PLAY mode will be automati-
cally engaged if a DOC, Disklavier or GM song disk
is inserted (and an accompaniment is not playing).
Otherwise engage the SONG PLAY mode as de-
scribed in the following step.
X Engage the Song Play Mode...........................................................................................................................................
Press the [SONG PLAY] button to engage the
SONG PLAY mode. The SONG PLAY display will
appear.
SONG
PLAY
CUSTOM
VOICE EDIT
FUNCTION
SONG
RECORD
CUSTOM
ACCOMP. REC
DISK
