50
V Save the Chain List, If Necessary .............................................................................................................................
The completed chain list can be saved to disk by
pressing the LIST SAVE LCD button. A confirma-
tion display will appear (“OK to save chain data?”):
press YES to save the list or NO to cancel.
NOTES
• Chain list data cannot be saved to a DOC or Disklavier
disk.
Song Playback & Recording
B
Return to the Song Select Display...........................................................................................................................
Press the SONG SEL. LCD button to return to the
SONG SELECT display.
Volume & Mute/Solo Settings
The volume, mute, and solo parameters for song
playback are available via the VOLUME/MUTE
display which can be accessed by pressing the [
]
LCD button to the right of the display. Press the
VOLUME or MUTE LCD button to switch to the
corresponding display.
