63
Song Playback & Recording
■ PLAYBACK .........................................................................................................................................................................................
Recorded tracks are automatically set to the
PLAY mode when recording is stopped, so you can
simply press the START LCD button or the [START]
panel button to hear what you’ve recorded immedi-
ately after recording. All other playback functions
are the same as described on the “Song Playback”
section (page 47).
Z Select a Track...................................................................................................................................................................................
Use the TRACK LCD [▲/▼] controls to select a
track for PUNCH IN recording: LEAD, RIGHT1,
RIGHT2, or LEFT. Only tracks which contain data
can be selected.
■ EXITING .................................................................................................................................................................................................
Press the [SONG RECORD] or [EXIT] button
to exit from the MULTITRACK RECORD mode
and return to the normal play mode.
SONG
PLAY
CUSTOM
VOICE EDIT
FUNCTION
SONG
RECORD
CUSTOM
ACCOMP. REC
DISK
EXIT
Punch-In Recording
PUNCH IN recording allows only a section of a recorded track to be re-recorded without having to redo the entire
track.
Select the PUNCH IN display via the [
] or [ ] LCD button to the right of the display.
NOTES
• If you require the metronome sound for punch-in record-
ing turn the METRONOME parameter ON in the PUNCH
IN display. The metronome settings are available in the
MULTI REC mode.
