70
Custom Accompaniment
V Copy the Data For the A or B Variation ...............................................................................................................
The COPY parameter makes it possible to copy
the A or B variation to the selected section, depend-
ing on the variation you want to program. The
possibilities are listed below:
SECTION COPY SOURCE
MAIN A or B MAIN A, MAIN B
INTRO INTRO A, INTRO B
FILL IN
FILL AA, FILL AB, FILL BB, FILL BA
ENDING ENDING A, ENDING B
Use the SOURCE LCD [▲/▼] controls to select
the section to be copied to the current section. Press
the EXECUTE button, then press YES to copy the
data when the confirmation display appears (or NO
to cancel).
B Enter a Style Name, If Necessary..............................................................................................................................
You can enter an original name for the custom
accompaniment style at this point. Style names can
be up to 12 characters long. Use the < > LCD [▲/
▼] control to move the name cursor to the various
character positions, then use the A~Z, a~z or
0~9… LCD [▲/▼] control to select the required
character for each position. The A~Z LCD [▲/▼]
control selects capital letters, the a~z LCD [▲/▼]
control selects lower-case letters, and the 0~9…
LCD [▲/▼] control selects numbers and special
characters.
N Go to the PART RECORD Display and Set Up the Tracks ...............................................................
Press the PART RECORD LCD button to go to
the PART RECORD display and use the LCD [▲/
▼] controls to set the REC mode for the part you
want to record. Other parts can be play-enabled or
muted as required. Parts which contain no data are
automatically set to MUTE.
