65
Song Playback & Recording
N Start Playback.................................................................................................................................................................................
Press the START LCD button or panel [START/
STOP] button to start playback from the current
PAUSE location.
M Start Recording at the Punch-in Point .................................................................................................................
Start recording at the punch-in point by either
pressing a START button, playing on the keyboard,
or pressing the footswitch, according to the start
trigger type selected in step 2, above.
< Stop Recording .............................................................................................................................................................................
Stop recording at the punch-out point by press-
ing the PUNCH OUT LCD button, the panel [START/
STOP] button, or the footswitch. If recording is
stopped via the panel [START/STOP] button, all
data following the punch-out point will be deleted.
If recording is stopped by using the PUNCH OUT
LCD button or footswitch, data following the punch-
out point will be left intact.
