The PSR-4000 “Functions”
In cases where the number of parameters in-
cluded in the function group is too large to fit on a
single display page, several pages may be available,
selectable via the
and LCD buttons.
■ The [EXIT] Button .......................................................................................................................................................................
The [EXIT] or [FUNCTION] button can be
used at any time to exit from a function and return to
the function menu. Pressing the [EXIT] or [FUNC-
TION] button while the FUNCTION MENU is
showing will return you to the normal play mode.
EXIT
In all cases the selected parameter can be edited
via the appropriated labeled or positioned LCD [▲/
▼] controls.
